Panda 24 PSC - fpControl with Land connection
- Nominal Output: 18,4 kW at 3000 m / +50 °C
- Output Voltage: 18,4 kW at 3000 m / +50 °C
- Output Current: 27,7 A
- Start System: 24 V Electrical
- Engine Type: FPV-1.5-T-MFHD
- Engine Cylinders: 4
- Fuel Supply: Integrated fuel tank (100 Liter)
- Frame / Mounting: Self contained unit mounted on frame with fork lift pockets
- Cooling System: Integrated radiator and fans mounted vertically for cooling
- Instrumentation & Electrical: Integrated electrical cabinet (instruments) and connections + remote control unit
- Approx. APU Weight (dry): 897 kg (dry)
Description
- Engine Manufacturer: Fischer Panda
- Engine Operating Temp. Range: with Webasto heater -32°C up to +50 °C without Webasto heater -15°C up to +50 °C
- Fuel Types: F 34, F 54 ,Standard automotive diesel fuel, kerosene, JP 8, JP 5, JET A
- Approx. Fuel Consumption: 1,7 -7,2 l/h
