Fischer Panda 4000 PSC-H AC Generator with fuel tank
- Nominal Output: 3,5 kW (constant) at 3000m / +55°C
- Output Voltage: 230 V 50 Hz single phase
- Output Current: 15,2 A
- Start System: 24 V Electrical
- Engine Type: Z482
- Engine Cylinders: 2
- Fuel Supply: Integrated Fuel Tank ( 24 litre capacity)
- Frame / Mounting: Self contained unit - with lifting eyes
- Cooling System: Integrated radiator and fans mounted horizontally for cooling
- Instrumentation & Electrical: Integrated electrical cabinet with instruments and connections
- Approx. APU Weight (dry): 371 kg
Description
- Engine Manufacturer: Kubota
- Engine Operating Temp. Range: -32°C up to +55°C (other temperature ranges on request)
- Fuel Types: 34, F 54 ,Standard automotive diesel fuel, kerosene, JP 8, JP 5, JET A
- Approx. Fuel Consumption: 0,8 - 1,4 l/h
